1. Motor type: 2-phase 4-wire system
2. Driving voltage: 5V / 300mA (the higher the voltage, the greater the force and the greater the heating)
3. Screw length: 36mm
4. Slide stroke: 34mm
5. Motor diameter: 10mm
6. Screw rod diameter: 2mm
7. Optical axis diameter: 1.5mm
8. Step angle: 18 degrees
9. Phase resistance: 15.5 Ω
10. Overall size: 50 * 10 * 10mm
11. Red a + white a-black B + brown B-
12. Note that the stepper motor, directly connected to the power will not rotate, the need for stepper motor drive board and control board
Fixed hole distance: about 12mm
