SOC characteristic：
Built-in Tensilica L106 ultra-low power 32-bit microprocessor with 80MHz and 160MHz frequency support, RTOS support
Built-in TCP/IP protocol stack
Built-in 1 10 bit high precision ADC
Peripheral interface HSPI, UART, I2C, I2S, IR Remote Control, PWM, GPIO
Deep sleep keeps current at 10uA and shutdown current is less than 5uA
Wake up, connect and pass packets within 2 ms
Standby power consumption is less than 1.0mW (DTIM3)
Built-in 1Mbyte SPI Flash
Wi-Ficharacteristic：
Support for 802.11 b/g/n/e/i
Support Station, SoftAP, SoftAP+STA mode
Support for Wi-Fi Direct (P2P)
Supports hardware acceleration of CCMP (CBC-MAC, counter mode), TKIP (MIC, RC4), WAPI (SMS4), WEP (RC4), CRC
P2P discovery, P2P GO mode/GC mode and P2P power management
WPA/PA2 PSK and WPS
802.11 i security features: pre-authentication and TSN
Support for 802.11n (2.4 GHz)
802.1h/RFC1042 frame packing
Seamless roaming support
Support AT remote upgrade and cloud OTA upgrade
Support for Smart Config (including Android and iOS devices)
range of working temperature:-40°C-125°C
Module size:26.8mm*16mm
Application scenario：
Household appliances · Home automation
Smart sockets, smart lights · Mesh network
Baby monitor · camera
Sensor network · Wearable electronics
Security ID tag · Wireless location awareness
Wireless positioning system beacon · Industrial wireless control
