1. The original chip CP2102, generate COM port after installing the driver.
2. Then the standard input MICRO MINI-USB cable connected to the computer USB interface, with 3.3V and 5V two power output
3. With a resettable fuse. In the event of accidental short-circuit can effectively protect your device and computer USB port to download
4. On-board status indicators, receiving indicator properly installed drive status indicator remains, send and receive indicator
flashes when the communication with run LED indicator.
5. Supports baud rates from 300bps ~ 1Mbps between
6. The communication format support: 1) data bits 5,6,7,8; 2) support 1.5, 2 stop bits; 3) odd, even, mark, space, none parity
7. Supported operating systems: windows 8.1 / 7 / vista / xp / 98, Mac OS-X / OS-9, Linux
8. USB seat MICRO MINI-USB interface Block
9. Chip components for the regular company of welding, stable quality, beautiful appearance
10. With DTR trigger signal output can be directly arduino pro mini ATMEGA328P and other Arduino board download traffic.
